Removing and installing components
This section includes these topics:
Topics
Component locations on page 73 Power button assembly on page 87 Expansion card slot identification
on page 121
Predisassembly procedures
on page 75
Optical disk drive (mini-tower
configuration) on page 89
Expansion card on page 124
Disassembly order on page 76 Optical disk drive (desktop
configuration) on page 93
Battery on page 128
Cable lock (optional) on page 77 Workstation speaker on page 97 Hard disk drive on page 129
Side access panel on page 78 Power supply on page 98 Liquid cooling solution on page 134
Side access panel sensor (optional)
on page 79
Power connections on page 99 CPU heatsink on page 154
Side access panel solenoid lock
on page 82
Fan assemblies on page 100 CPU on page 157
Bezel on page 83 Airflow guide on page 110 System board on page 159
Front panel I/O device assembly
on page 83
Memory on page 116 Converting to desktop configuration
on page 161
