Top
TouchPad
Component Description
(1) Pointing stick Moves the pointer and selects or activates items on the screen.
(2) Left pointing stick button Functions like the left button on an external mouse.
(3) TouchPad on/off button Turns the TouchPad on and off.
(4) TouchPad zone Reads your finger gestures to move the pointer and select or
activate items on the screen.
NOTE: The TouchPad also supports edge-swipe gestures. For
more information, see Edge swipes (select models only) on
page 34.
(5) Left TouchPad button Functions like the left button on an external mouse.
(6) Right pointing stick button Functions like the right button on an external mouse.
(7) Center pointing stick button Functions like the center button on an external mouse.
(8) Center TouchPad button Functions like the center button on an external mouse.
(9) Right TouchPad button Functions like the right button on an external mouse.
8 Chapter 2 External component identification
