Display assembly
NOTE: The DreamVision display assembly is spared as a whole unit assembly only. The LED display
assembly is spared at the subcomponent level only. For more LED display assembly spare part information,
see the individual removal subsections.
Description Spare part number
15.6-in, FHD, UWVA, DreamVision display assembly equipped with a webcamera 735965-001
15.6-in, FHD, UWVA, DreamVision display assembly not equipped with a webcamera 735964-001
To remove the display assembly and access the LED display assembly subcomponents, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44), and then remove the following components:
a. Service cover (see
Service cover on page 45)
b. Hard drive (see
Hard drive on page 46)
c. Optical drive (see
Optical drive on page 48)
d. Keyboard (see
Keyboard on page 57)
e. Top cover (see
Top cover on page 65)
Remove the display assembly:
1. Close the computer.
2. Turn the computer upside down, with the rear toward you.
3. Make sure that the WWAN antenna cables are disconnected from the WWAN module (see
WWAN module
on page 50).
4. Make sure that the WLAN antenna cables are disconnected from the WLAN module (see
WLAN module
on page 53).
Component replacement procedures 87
