Item Component Spare part number
●
16-GB 862396-852
●
8-GB 862398-852
●
4-GB 862397-852
For use in models with Xeon Core processors
●
16-GB 835886-002
●
8-GB 835887-002
Heat sink assembly (includes replacement thermal material)
(15) For use only in models with UMA graphics memory 922938-001
(16) For use only in models with Nvidia Quadro M1200 and M620 graphics boards 922935-001
(16) For use only in models with Nvidia Quadro M2200 graphics boards 922936-001
(16) For use only in models with the AMD Radeon Pro graphics board 922937-001
(17) Solid-state drive (SSD); M.2
SATA-3 drives, TLC:
●
512-GB, FIPS 921052-001
●
256-GB, TLC 932478-001
●
256-GB, self-encrypting drive (SED), OPAL 2 921053-001
Z Turbo drives; PCIe:
●
1-TB, MLC 921057-001
●
512-GB, self-encrypting drive (SED), OPAL 2, TLC 921054-001
●
512-GB, MLC 921056-001
●
256-GB, TLC 921055-001
●
256-GB, MLC 921051-001
(18) WWAN module
HP lt4120 LTE/EVDO/HSPA+ Gobi 4G Mobile Broadband Module 800870-002
Fibocom HP hs3210 WW HSPA+ w/o GPS 918670-852
Huawei HP It4132, LTE/HSPA+ 4G w/GPS M.2 918671-852
(19) WLAN module
Intel Dual band wireless-AC 8265 802.11AC 2x2 WiFi + BT 4.2 Combo Adaptor (non-vPro) 910264-852
Intel Dual band wireless-AC 8265 802.11AC 2x2 WiFi + BT 4.2 Combo Adaptor (vPro) 918855-852
Fan
(20) Fan for use near the processor 848251-001
(21) Fan for use near the graphics board 848252-001
(22) System board (includes replacement thermal material)
All system boards use the following part numbers:
20 Chapter 3 Illustrated parts catalog
