d. Remove the display panel from the display enclosure (3).
NOTE: The display assembly will not be connected to the computer as shown in the following
image.
e. Remove the display panel.
The display panel is available using the following spare part numbers:
SVA panel with display cable: 936518-001
UWVA panel with display cable: 936519-001
SVA panel without display cable: 819354-004
UWVA panel without display cable: 819355-005
13. If it is necessary to replace the camera/microphone module or microphone module:
CAUTION: Handle the camera/microphone module and microphone module with caution. These
modules have a thin prole and are susceptible to damage when not handled carefully.
a. Detach the camera/microphone module (1) from the display enclosure. (The camera/microphone
module is attached to the display enclosure with adhesive.)
b. Disconnect the cable (2) from the camera/microphone module.
Component replacement procedures 69
