HP ZBook 15 User Manual

Category Description
Panel
●
15.6-in, full-high definition (FHD), AntiGlare (AG), RGB, light-emitting diode (LED),
UWVA (1920×1080 resolution, 210 nits, 109% CG), DreamColor (7.2-mm,
wedge design, eDP panel) with camera, not available with WWAN capability
●
15.6-in, FHD, AG, RGB, LED, UWVA, DreamColor, without camera, not available
with WWAN capability
●
15.6-in, FHD, AG, LED, UWVA (1920×1080 resolution, 300 nits, 72% CG slim),
non-DreamColor (3.8-mm flat design, eDP panel) with camera
●
15.6-in, FHD, AG, LED, UWVA, non-DreamColor without camera
●
15.6-in, FHD, AG, LED, SVA with camera
●
15.6-in, FHD, AG, LED, SVA without camera
All panels are 16:9 aspect ratio
Memory Four customer-accessible/upgradable memory module slots
Support for DDR3L 1600-MHz PC3-12800 dual channel memory
Support for 8192-MB of system RAM in the following configurations:
●
32768-MB total system memory (8192-MB×4)
●
16384-MB total system memory (8192-MB×2 or 4096-MB×4)
●
8192-MB total system memory (8192-MB×1 or 4096-MB×2)
●
4096-MB total system memory (4096-MB×1)
Flash cache 32-GB MLC mSATA module (Intel Smart Response Technology (SRT)
Dedicated MiniCard slot
Support for no flash cache option
Fast Flash Standby not supported
Not available on computer models equipped with a solid-state drive (SSD) or a self-
encrypted drive (SED)
Not available on computer models equipped with the Linus operating system
MiniCard solid-state drive 128-GB mSATA SSD
Not available if 32-GB flash cache is selected
SSD is set as primary storage if selected; hard drive becomes secondary storage
2 Chapter 1 Product description

HP ZBook 15 Specifications

General

Form factor	Clamshell
Product type	Mobile workstation
Product color	Black
Country of origin	China
Bus type	DMI2
Stepping	C0
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
Processor model	i7-4900MQ
System bus rate	- GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4900 Mobile Series
Processor socket	PGA946
Processor threads	8
Processor codename	Haswell
Processor frequency	2.8 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.8 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	47 W
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM87
Memory slots	4x SO-DIMM
Internal memory	16 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
Optical drive type	Blu-Ray DVD Combo
Card reader integrated	Yes
Total storage capacity	256 GB
Compatible memory cards	SD
Number of SSDs installed	1
Display diagonal	15.6 \
Native aspect ratio	16:9
On-board graphics card ID	0x416
Discrete graphics card model	NVIDIA® Quadro® K1100M
On-board graphics card model	Intel® HD Graphics 4600
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1300 MHz
Audio system	DTS Studio Sound HD
Number of built-in speakers	2
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Keyboard layout	-
Recovery operating system	Windows 8 Pro
Operating system installed	Windows 7 Professional
Processor code	SR15K
Processor ARK ID	75131
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 x 4.7 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Battery capacity	83 Wh
Battery life (max)	- h
AC adapter power	150 W
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	257 mm
Width	381.5 mm
Height	30.5 mm
Weight	2820 g
