Cable Kit
Item
Component
Spare part number
Cable Kit
, includes:
734283-0
01
(1)
RJ-45 (network) cable
(2)
Power connector cable
Replacement thermal material (not illustrated)
32
Chapter
3 Illustra
ted parts ca
talog
39
41
