Solid-state drive
Description Spare part number
512-GB SATA-3 SSD 738714-001
256-GB SATA-3 self-encrypting SSD 735598-001
180-GB SATA-3 SSD 735597-001
128-GB SATA-3 SSD 735596-001
128-GB mSATA-3 SSD 735595-001
32-GB mSATA flash cache SSD 735594-001
Before removing the solid-state drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 50).
5. Remove the service cover (see
Service cover on page 51).
Remove the solid-state drive:
1. Remove the two Phillips PM2.0×3.5 screws (1) that secure the solid-state drive to the system
board. (The solid-state drive tilts up.)
2. Remove the solid-state drive (2) by pulling the drive away from the slot at an angle.
58 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
