Fingerprint reader board
Description Spare part number
Fingerprint reader board (includes cable and double-sided adhesive) 734286-001
Before removing the fingerprint reader board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 50), and then remove the following components:
a. Service cover (see
Service cover on page 51)
b. Hard drive (see
Hard drive on page 52)
c. Optical drive (see
Optical drive on page 54)
d. Keyboard (see
Keyboard on page 62)
e. Top cover (see
Top cover on page 71)
Remove the fingerprint reader board:
1. Turn the top cover upside down with the front toward you.
2. Remove the Phillips PM2.0×3.0 screw (1) that secures the fingerprint reader board and bracket to
the top cover.
3. Slide the fingerprint reader board (2) bracket forward and remove it.
The fingerprint reader board bracket is available in the Bracket Kit, spare part number
734299-001.
4. Detach the fingerprint reader board cable (3) from the top cover. (The fingerprint reader board
cable is attached to the top cover with double-sided adhesive.)
Component replacement procedures
75
