Speakers
Description Spare part number
Speakers (includes cable) 734292-001
Before removing the speakers, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 50), and then remove the following components:
a. Service cover (see
Service cover on page 51)
b. Hard drive (see
Hard drive on page 52)
c. Optical drive (see
Optical drive on page 54)
d. Keyboard (see
Keyboard on page 62)
e. Top cover (see
Top cover on page 71)
Remove the speakers:
1. Disconnect the speaker cable (1) from the system board.
2. Remove the two Phillips PM2.0×3.0 screws (1) that secure the speakers to the base enclosure.
Component replacement procedures
89
