HPE Aruba Networking CX 6200M

Switches Fan Tray 1 Fan Tray 2
6200M 24G 4SFP+ TAA switch
(R8V08A)
HPEAruba Networking CX
6200M 48G Class4 PoE 4SFP+
switch (R8Q70A)
Required Optional
HPEAruba Networking CX
6200M 48G Class4 PoE 4SFP+
TAA switch (R8V11A)
Required Optional
HPEAruba Networking CX
6200M 24G Class4 PoE 4SFP+
switch (R8Q68A)
Required Optional
HPEAruba Networking CX
6200M 24G class4 PoE 4SFP+
TAA switch (R8V09A)
Required Optional
Table 2: Fan information for 6200M switches: HPEAruba Networking CX 6200M 24G 4SFP+ switch (R8Q67A);
HPEAruba Networking CX 6200M 24G Class4 PoE 4SFP+ switch (R8Q68A); HPEAruba Networking CX 6200M
48G 4SFP+ switch (R8Q69A); HPEAruba Networking CX 6200M 48G Class4 PoE 4SFP+ switch (R8Q70A); and
HPEAruba Networking CX 6200M 36G 12SR5 Class6 PoE 4SFP+ switch (R8Q71A)
Fan Condition Fan Speed Fan Redundancy Shutdown
System installed with 2 fan trays
4 fans functioning
normally
According to ambient and
component temperature
N+1 Component hits thermal limit
1 fan fault Remaining fans will spin at Max
speed
Not supported Component hits thermal limit
More than 1 fan
fault
Remaining fans will spin at Max
speed
Not supported Upon detection, system will be
shut down in 3 minutes or
component hits thermal limit
System installed with 1 fan tray
2 fans functioning
normally
According to ambient and
component temperature
Not supported Component hits thermal limit
1 fan fault Remaining fans will spin at Max
speed
Not supported Upon detection, system will be
shut down in 3 minutes or
component hits thermal limit
2 fans fault N/A Not supported Upon detection, system will be
shut down in 3 minutes or
component hits thermal limit
System with no fan tray
Missing both fan
tray/all fans faulted
N/A Not supported Upon detection, system will be
shut down in 3 minutes or
component hits thermal limit.
