Ref.
Code
Function Setting Range Default Remark
Communication Parameters
F17.00 Data format
0: 1-8-2 format, no parity,
RTU
1: 1-8-1 format, even parity,
RTU
2: 1-8-1 format, odd parity,
RTU
6: 1-8-1 format, no parity,
RTU
0
F17.01 Baud rate selection
0: 1200bps
1: 2400bps
2: 4800bps
3: 9600bps
4: 19200bps
5: 38400bps
6: 57600bps
7: 76800bps
8: 115200bps
3
HD09/
HD20
does n
,
t
have
6 - 8
F17.02 Local address 0 - 247 2
Ref.
Code
Function
Fault Parameters
F20.21 Fifth (latest) failure type
F20.22 Given frequency at the last fault
F20.23 Running frequency at the last fault
F20.24 Bus voltage at the last fault
F20.25 Output voltage at the last fault
F20.26 Output current at the last fault
F20.27 Input terminal status at the last fault
F20.28 Output terminal status at the last fault
F20.29 Interval at the last fault
F20.30 Fourth fault type
F20.31 Fourth fault interval
F20.32 Third fault type
F20.33 Third fault interval
F20.34 Second fault type
F20.35 Second fault interval
F20.36 First fault type
F20.37 First fault interval
F20.38 Last fault interval
Function Parameters
