Fault Countermeasure Remark
No display when power on
Check the input power voltage
Check the bus voltage
Reconnect the keypad, or check the
wiring of the control board, drive
board, and keypad
Contact factory for repair
-Lu-
DC bus
undervoltage
Normal power-on and power-down
status, no processing required
Check input power voltage
Check wiring and wire the inverter
properly
E0001
Inverter output
overcurrent (Acc.)
Connect the inverter and motor
properly
Correctly set F08.00 - F08.04/
F13.01 - F13.05 (motor parameters)
Choose the right inverter power
Set proper F03.01 - F03.08 (Acc. and
Dec. time)
Select the speed tracking start mode
(F02.00 = 2)
Perform parameter auto-tuning
(F08.06/F13.07)
E0002
Inverter output
overcurrent (Dec.)
E0003
Inverter output
overcurrent
(constant speed)
E0004
DC bus overvoltage
(Acc.)
Check input power voltage
Set proper F03.02/F03.04/F03.06/
F03.08 (Dec. time)
Check wiring and wire the inverter
properly
Select the speed tracking start mode
(F02.00 = 2)
Select the recommended braking
devices
E0005
DC bus overvoltage
(Dec.)
E0006
DC bus overvoltage
(constant speed)
E0007 Overvoltage stall
Check power input or the function of
brake
Set proper F19.19 (overvoltage stall
point)
E0008
Power module
fault
Check wiring and wire the inverter
properly
Check the connection and
mechanism
Contact the supplier for repairing
HD07-S
none
E0009 Heatsink overheat
Derated use, amplified power
Improve the ventilation around the
inverter
Replace the fan
Seek technical support
E0010 Brake unit fault Seek technical support
E0011 CPU fault
Power on and observe after
completely power down
Seek technical support
HD07-S
none
E0012
Parameter auto-
tuning fault
Check the motors connection
Correctly set F08.00 - F08.04/
F13.01 - F13.05 (motor parameters)
Seek technical support
E0013
Contactor is not
actuated
Replace the contactor
Seek technical support
HD07-S
none
E0014
Current detection
circuit fault
Contact the supplier for repairing
E0015 Input phase loss
Check three-phase input power
Seek technical support
HD09/
HD09-S
none
E0016 Output phase loss
Check the wiring between the
inverter and the motor
Check motor quality
E0017 Inverter overload
Adjust F03.01/F03.03/F03.05/F03.07
(Acc. time)
Correctly set F08.00 - F08.04/
F13.01 - F13.05 (motor parameters)
Adjust F09.00 - F09.06 (V/f curve) or
F09.07/F09.08 (torque boost)
Perform parameter auto-tuning
(F08.06/F13.07)
Select the speed tracking start mode
(F02.00 =2)
Check mains supply voltage
Select a power-matched inverter
Troubleshooting
