Chapter 2 Product Information Shenzhen Hpmont Technology Co., Ltd
―8― HD30 Series Inverters User Manual
Item Specification
Display panel
LED display
Five-segment LED display
Setting frequency, output frequency, output voltage, output current,
motor speed, output torque, switching value terminal, status parameter,
programm menu parameter and fault code etc.
LCD display Optional (HD-LCD), display operation contents in Chinese or English
Parameter copy Both LED and LCD display panel can achive quick parameter copy
Pilot lamp 5 unit indicators, 5 status indicators
Environment
Operation
temperature
-10－+40℃, air temperature fluctuation is less than 0.5℃/min
The derating value of the output current of the inverter shall be 2% for
each degree centigrade above 40℃. Max. allowed temperature is 50℃
Storage temperature -40－+70℃
Location for use
Indoor, preventing from direct sunlight, no dust, corrosive, flammable
gases, oil mist, water vaper, dripping or salt etc.
Altitude Less than 1000 meters, otherwise should be derating use
Humidity Less than 95%RH, non-condensing
Ocsillation Less than 5.9m/s
2
(0.6g)
Options
Extended I/O
Additional I/O option (HD30-EIO)
Pump switching option (HD30-WIO)
Plastic interface option (HD30-PIO)
Bus communication
PROFIBUS option (HDFB-PROFIBUS-DP)
DeviceNet option (HDFB-DeviceNet)
CAN option (HDFB-CAN)
About display panel
Status display panel (HD-LED-L)
LED display pane with potentiometer (HD-LED-P)
LCD display panel (HD-LCD)
Display panel is connecting with mounting seat (HD-KMB)
Display panel is connecting with 1 meter cable (HD-CAB-1M)
Display panel is connecting with 3 meters cable (HD-CAB-3M)
Display panel is connecting with 6 meters cable (HD-CAB-6M)
Enhanced protection Protective cover (HD-CK-Frame4)
Power units
Energy depletion braking unit (HDBU)
Energy depletion feedback unit (HDRU)
2.4 Ratings
Model HD30-
Rated capacity
(kVA)
Rated input
current(A)
Rated output
current(A)
Motor power(kW)
Single/three-phase power supply: 200
240V, 50/60Hz
2D0P4G 1.0 5.8 2.5 0.4
2D0P7G 1.5 10.5 4.0 0.75
2D1P5G 2.8 18.5 7.5 1.5
2D2P2G 3.8 24.1 10 2.2
To Next Page
