Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―78― HD30 Series Inverters User Manual
No. Name Description Range
factory setting
F10.09 Reserved
F10.11 Motor torque limitation when motor 1 is forward 0.0
200.0% motor rated
current
180.0%
Motor torque limitation when motor 1 is reverse
F10.13 Recreated torque limitation when motor 1 is forward
Recreated torque limitation when motor 1 is reverse
6.2.12 Group F11 Reserved
6.2.13 Group F12 Reserved
6.2.14 Group F13 Asynchronous Motor 2 Parameters
This group can be set as the second group of motor parameters and control parameters
corresponding to the first group parameters (motor 1). The concrete meaning refers the
corresponding parameters of motor 1 and achieves flexible switching between the 2 motors (refer
to multi-function input terminal No. 47 function).
Note:
Refer to Group F08 Asynchronous Motor 1 parameters for F13.01－F13.15.
Refer to Group F09 V/f Control parameters for F13.16－F13.34.
Refer to Group F10 Motor 1 Vector Control Speed-loop Parameters for F13.35－F13.49.
No. Name Description Range
factory setting
Control mode selection of motor 2
0: V/f control without PG.
1: Reserved.
2: Vector control without PG.
F13.01 Rated power of motor 2 0.2
500.0kW
dependent on
F13.02 Rated voltage of motor 2 0
inverter rated voltage
dependent on inverter
model
F13.03 Rated current of motor 2 above 5.5KW 0.0
999.9A
dependent on
5.5KW or below 0.00
99.99A
dependent on
inverter model
Rated frequency of motor 2
F13.05 Rated speed of motor 2 1
24000rpm
1440
F13.06 Power factor of motor 2 0.001
1.000
dependent on
To Next Page
