TP809 User Manual
20
5.5 Power Supply Interface
Figure 5-5
PIN NO.
SIGNAL NAME
1
+24V
2
GND
3
N.C
SHELL
F.G
Printer end: Unetop DC-002 or similar products;
User end: Unetop DC-002 or similar products.
