1. Insert the headset into the USB
connector before doing the testing.
2. Tap icon FM Radio in the programs
of the menu.
3. Select the different channels for
testing.
Audio Test-1
1. Download test program from SDO
(GSD-00004973)
http://htcscm10.htc.com.tw/SDO
2. Un-zip the image file.
3. Copy “mfgtest.dll” and “Audio
T
est.exe” to internal storage.
4. Execute ”Audio Test” program from
internal stor
age.
5. Choose the each test in the menu of
“T
ools”
Audio Test-2
6. Select the Speaker Test then press
Play button for testing
Audio Test-3
