7. Select the Speaker Test then press
Play button for testing
Audio Test-4
8. Connect the headset into the USB
port before doing the testing
9. Select the Headset Test then press
Play button for testing
Audio Test-5
10. Select the Int-Rec Test then press
the “Record” button for voice
recording first
11. Stop the voice record then press
“Play” button for intern
al receiver
test
