6. Record information such as CPU models and quantity and
DIMM vendor, quantity, and capacity displayed on the BIOS
screen. Check whether the displayed models and quantity are
the same as those recorded in section 4.1.1.
7. Press F9 to restore default settings, and then press F10 to save
the settings and exit.
Expected Results The server is properly powered on and the BIOS screen is
displayed. The component information displayed on the BIOS is
the same as that recorded in section 4.1.1.
Test Result
Remarks
4.1.5 Configuring a RAID Array for Hard Disks
Case No.
4.1.5
Test Objective To verify that a RAID array can be configured for hard disks on the
server.
Test Networking
Diagram
N/A
Prerequisites The server is powered on.
Procedure
NOTE
Before installing an OS for the server, configure a RAID array as required. For
example, configure RAID 1 if the server has two hard disks, or RAID 5 if the
server has three or more hard disks.
Create a RAID array using a controller card supported by the server.
For details, see the Huawei V5 Server RAID Controller Card User
Guide.
Expected Results A RAID array is successfully configured.
5288 V5 Server
Acceptance Guide
4 Test Cases and Records
Issue 03 (2019-03-25) Copyright © Huawei Technologies Co., Ltd. 11
