Procedure On the iBMC WebUI, choose Information > System Info.
Check the following information:
Processor information (manufacturer, model, frequency, number
of cores, and cache)
Memory information (manufacturer, capacity, frequency, type,
voltage, bit width, and serial number)
PSU information (manufacturer, rated power, and input mode)
Fan module information (model, speed, and speed ratio)
Expected Results
Component information is queried successfully on the iBMC
WebUI.
Test Result
Remarks
4.3 Reliability Test
4.3.1 Testing PSU Redundancy
Case No.
4.3.1
Test Objective To verify that PSUs on the server work in redundancy mode.
Test Networking
Diagram
See section 2.1 Network Diagram.
Prerequisites
l The server is powered on.
l A Linux OS has been installed on the server.
5288 V5 Server
Acceptance Guide
4 Test Cases and Records
Issue 03 (2019-03-25) Copyright © Huawei Technologies Co., Ltd. 18
