5. Select IPv4 IP Address and press Enter. You can query or
change the IP address for the iBMC management network
port.
6. Save the setting and exit. Note: The iBMC does not need to be
restarted for the setting to take effect.
Expected Results
The server iBMC IP address is successfully queried and changed.
The iBMC IP address can be successfully pinged from a PC on
the same network segment as the iBMC IP address.
Test Result
Remarks The default iBMC IP address is 192.168.2.100.
4.2.4 Powering On and Off the Server Remotely
Case No.
4.2.4
Test Objective To verify that the server can be remotely powered on and off.
5288 V5 Server
Acceptance Guide
4 Test Cases and Records
Issue 03 (2019-03-25) Copyright © Huawei Technologies Co., Ltd. 16
