Y210 Mobile Phone
Maintenance Manual
8 Assembly Procedure
Issue 1.0 (2012-11-28)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
18
10. Gently press the PCBA to close the latches and
secure the PCBA.
9. Place the PCBA on the front cover. Ensure that the
PCBA is in good contact with the front cover at the
power button position. Snap the latches in place.
8. Install the LCD. Ensure that the two latches are
snapped in place and that the LCD is even.
7. Remove the protective film from the LCD.
6. Install the power button FPC.
5. Install the receiver.
