Huawei BTS3012 Installation Guide

HUAWEI BTS3012 Fast Installation Guide Internal Use
5
Fix the base
Install the insulation shells, flat washers, spring washers, and bolts in a correct order.
Adjust the
levelness
Use a horizontal ruler to check the levelness of two horizontal borders on the top of the bottom
frame. If the bottom frame is out of the horizontal, add leveling washers below the insulation plate
to level the bottom frame.
Check the
insulativity
Check the resistance of the bottom frame.
 If the resistance is equal to or bigger than 5MΩ, the bottom frame is insulated from the ground.
You can fix the cabinet then.
 If the resistance is smaller than 5MΩ, the bottom frame is not insulated. You need check the
bottom frame and ensure that it is correctly installed.
