19
Installing the BTS3900C Cables
1. Remove the outer screw
from the waterproof unit.
3. Lead the cable to be installed from the
bottom of the cable trough to the
corresponding cable hole in the waterproof
unit. Do not link the connector of the cable to
any port.
4. Link the connectors of the cables to the
ports on the corresponding devices after
all the cables are lead through the cable
holes of the waterproof unit.
For details about the cable holes, cable routes, and
installation methods, see the following installation
procedures.
a
2. Remove the waterproof
unit from the cable trough.
Installing the Cables through the cable hole
To Next Page
