7
Installing the BTS3900C Cabinet
1. Use four bolts to combine the OMB
subrack and the RRU subrack.
2. Remove the attachment plates
on the side of the OMB subrack.
a
Assembling the BTS3900C Cabinet
3. Install the removed attachment plates onto the back of the cabinet, use
retention screws to fix the attachment plates, and then tighten the four bolts to
fasten the two subracks.
M4
M6x12
To Next Page
