29
Installing the BTS3900C Cables
Installing the Signal Cables
e
Install the AISG multi-wire cable (in the BTS3900C configured with the RRU3804).
The AISG multi-wire cable is used when the RET antenna is required. The cable is
lead from the RET/PWR_SRXU port at the bottom of the RRU to the RET port.
The procedures for installing the AISG multi-wire cables in the BTS3900C DC cabinet configured with the
RRU3804 and in the BTS3900C AC cabinet configured with the RRU3804 are the same.
