HUAWEI ME906s LTE M.2 Module
Hardware Guide
RF Specifications
Issue 05 (2019-03-25)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
46
Operating Band
Tx
Rx
LTE Band 5
824 MHz–849 MHz
869 MHz–894 MHz
LTE Band 7
2500 MHz–2570 MHz
2620 MHz–2690 MHz
LTE Band 8
880 MHz–915 MHz
925 MHz–960 MHz
LTE Band 20
832 MHz–862 MHz
791 MHz–821 MHz
LTE Band 28
703 MHz–748 MHz
758 MHz–803 MHz
GPS L1
-
1574.42 MHz–1576.42 MHz
GLONASS L1
-
1597.55 MHz–1605.89 MHz
4.3 Conducted RF Measurement
4.3.1 Test Environment
Test instrument
R&S CMU200, R&S CMW500, Agilent 8960, Anritsu
MT8820C
Power supply
Keithley 2303, Agilent 66319
RF cable for testing
Rosenberger Precision Microwave Cable
Murata coaxial
cable
MXHP32HP1000

The compensation for different frequency bands relates to the cable and the test
environment.

The instrument compensation needs to be set according to the actual cable conditions.
4.3.2 Test Standards
Huawei modules meet 3GPP test standards. Each module passes strict tests at the
factory and thus the quality of the modules is guaranteed.
4.4 Conducted Rx Sensitivity and Tx Power
4.4.1 Conducted Receive Sensitivity
The conducted receive sensitivity is a key parameter that indicates the receiver
performance of ME906s.
