3 Description of the Application Interfaces
3.1 About This Chapter
This chapter mainly describes the application interfaces of the ME906s module,
including:

75-pin Gold Finger

Power Interface

Signal Control Interface

USB Interface

USIM Card Interface

Tunable Antenna Control

Config Pins

Reserved Pins

NC Pins

RF Antenna Interface
3.2 75-pin Gold Finger
The ME906s module uses a 75-pin Gold Finger as its external interface. For details
about the module dimensions, see 6.2 Dimensions.
Figure 3-1 shows the sequence of pins on the 75-pin signal interface of the ME906s
module.
