Huawei ME906s LTE M.2 - Power Consumption

HUAWEI ME906s LTE M.2 Module
Hardware Guide
Electrical and Reliability Features
Issue 05 (2019-03-25)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
55
5.4.2 Power Consumption
The power consumption of ME906s in different scenarios are respectively listed in
Table 5-5 to Table 5-9 .
The power consumption listed in this section are tested when the power supply of
ME906s module is normal voltage (3.3 V), and all of test values are measured at
room temperature.
Table 5-5 Averaged power off DC power consumption
Description
Test Value (Unit: uA)
Notes/Configuration
Typical
Power off
70
Normal voltage (3.3 V) is ON and
Power_On_Off pin is pulled low.
Table 5-6 Averaged standby DC power consumption (WCDMA/HSDPA/LTE/GSM)
Description
Bands
Test Value (Unit: mA)
Notes/Configuration
Typical
Sleep
LTE
LTE bands
2.64
Module is powered up.
DRX cycle=8 (2.56s)
Module is registered on the
network.
USB is in suspend.
HSPA+/WCDMA
UMTS bands
1.70
Module is powered up.
DRX cycle=8 (2.56s)
Module is registered on the
network.
USB is in suspend.
GPRS/EDGE
GSM bands
2.74
Module is powered up.
MFRMS=5 (1.175s)
Module is registered on the
network.
USB is in suspend.
Radio Off
All bands
1.07
Module is powered up.
RF is disabled.
USB is in suspend.
