Huawei ME906s LTE M.2 - Mechanical Specifications; About This Chapter; Dimensions

HUAWEI ME906s LTE M.2 Module
Hardware Guide
Mechanical Specifications
Issue 05 (2019-03-25)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
65
6 Mechanical Specifications
6.1 About This Chapter
This chapter describes the following aspects of the ME906s module:

Dimensions

Packing System
6.2 Dimensions
Figure 6-1 shows the dimensions of ME906s in details.
Figure 6-1 Dimensions (Unit: mm)
