HUAWEI ME909u-521 LTE LGA Module
Hardware Guide
Description of the Application Interfaces
Issue 05 (2017-12-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
13
3 Description of the Application Interfaces
3.1 About This Chapter
This chapter mainly describes the external application interfaces of the ME909u-521
module, including:

LGA Interface

Power Interface

Signal Control Interface

UART Interface

USB Interface

USIM Card Interface

Audio Interface

General Purpose I/O Interface

JTAG Interface

RF Antenna Interface

Reserved Interface

NC Interface

Tunable Antenna Control
3.2 LGA Interface
The ME909u-521 module uses a 145-pin LGA as its external interface. For details
about the module and dimensions, see 6.4 Dimensions and Interfaces.
