Huawei NetCol8000-A - Page 11

10
Model
Width (W1)
Depth (D1)
Height (H)
Distance
between the
centers of two
platforms at
the length
side (W2)
Distance
between the
centers of two
platforms at
the width side
(D2)
NetCol500
-A110
W1 ≥ 250
D1 ≥ 250
150
～250
1035
1076
Concrete platform dimensions (unit: mm)
Vertical Installation (Choose One from the Two Installation Scenario)
4.4
Model
Width (W1)
Depth
(D)
Height
(H)
Height (W2)
E
NetCol500
-A060 (52273539,
52273539
-005)
W1 ≥ 300
D ≥ 500
150
～250
1150
1037
NetCol500
-A060 (52273539-006)
W1 ≥ 300
D ≥ 500
150
～250
1120
978
NetCol500
-A080
W1 ≥ 300
D ≥ 500
150
～250
1920
1742
NetCol500
-A120
W1 ≥ 300
D ≥ 500
150
～250
2120
1217
Concrete platform dimensions (unit: mm)
NetCol500-A060/A080/A120
The strength level of the concrete platform must be equal to or greater than C20.
