Installing the Service Cables for the Equipment – DC Power
Supply
Installation Effectiveness of the Service Cables
a
For the details on how to route service cables, see "Installing the Service Cables for the Equipment
– AC Power Supply. "
E1 cable (transit cable)
E1 cable (lead-out cable)
Ethernet cable (transit
cable)
Ethernet cable (lead-out
cable)
IF cable
Monitoring cable
Fiber
NOTE
FE0
FE0
UFLP
INSIDE
FE1
7
OUTSIDE
FE1
5
4
2
1
8
6
3
