Huawei Quidway 3600 Series User Manual

Installation Manual
Quidway R2600/3600 Series Modular Routers
Chapter 2
Appearance and System Features
2-4
Table 2-4 Meanings of indicators on the front panel of R2630/R2630E
Indicator Meaning
POWER System power indicator: Off means power is off, On means power is on.
SYSTEM
Hardware status indicator. Blinking means the system runs normally. Always on/off
means the system is abnormal.
READY
Module status indicator: On means the module in corresponding slot runs normally.
Off means the module runs abnormally or no module is installed.
ACTIVE
Blinking means data is being received or transmitted by the module in the
corresponding slot. Off means no data is being received or transmitted
0 - 2 Indicating the slot number.
LAN
Ethernet interface indicator: Green means the interface is normal. Blinking yellow
means data is being received and transmitted over the Ethernet.
Table 2-5 Meanings of indicators on the rear panel of R2630/R2630E
Indicator Meaning
LINK Off means the Ethernet link is not connected. On means the link is connected.
ACTIVE
Off means no data is being received and transmitted by the Ethernet interface.
Blinking means data is being received or transmitted.
2.2.3 System Description
The following table shows the basic configuration, dimensions, operating environment,
etc. of R2630 and R2630E.
Table 2-6 System description of R2630/R2630E
Item Description of R2630 Description of R2630E
Slot
A maximum of 3 interface modules can be configured according to
requirement.
CPU Pentium 133MHz Power PC 8240 200MHz
NVRAM 128KB 128KB
BOOTROM 512KB 512KB
Default: 64MB
SDRAM None
Max.: 256MB
Default: 32MB
DRAM
Max.: 128MB
None
FLASH 8MB
Dimensions Width x Height x Depth = 440mm x 43mm x 400mm
Weight 8kg
AC: 160 to 240V 50/ 60Hz AC: 85 to 264V 50/60Hz
Input voltage
DC: -40 to -75V
Max. power 80W
Operating temperature 0 to 40
O
C
Operating humidity 10 to 90% non-condensing



Note:
Dynamic memory (DRAM/SDRAM) works as main memory.
FLASH stores system programs.
NVRAM stores configuration files.
