Installation Manual
Quidway R2600/3600 Series Modular Routers
Chapter 8
Function Modules
8-20
Note:
The pins not referenced in the above table are not connected.
z V.35 DCE
Pos.1
Pos.50
Enlarged B side
DB50 Male
Label
B
V.35 Female
Female
Enlarged A side
A
Figure 8-24 Cable connection via V.35 DCE
