Figure B-9 Example of the label on the optical fiber between two devices
A01
R
TO:
01 05 01
G01
T
01
01
01
The meaning of the labels is listed in Figure B-9.
l “A0-01-05-01-R” indicates that the local end of the optical fiber is connected with the
optical receiving interface 01 on slot 5, chassis 01 in the cabinet on row A, column 01 in
the machine room.
l “G01-01-01-01-T” indicates that the opposite end of the optical fiber is connected with
Optical Transmitting Interface 01 on Slot 01, Chassis 01 in the cabinet on Row G, Column
01 in the machine room.
B.2.2 Labels for the Optical Fibers Connecting the Device and an
ODF
Meaning of the Labels
Table B-3 shows the information on both sides of the labels affixed to the optical fiber that
connects the device and the ODF.
Table B-3 Information on labels affixed to the fiber between the device and the ODF
Content
Meaning Example
MN-B-C-D-
R/T
MN: cabinet
number
For example, A01.
B: chassis
number
Numbered in bottom-up order with two digits, for
example, 01.
C: physical slot
number
Numbered in bottom-up order with two digits, for
example, 01.
D: optical
interface
number.
Numbered with two digits in up-bottom and left-right
order. For example, 01.
R: Optical
receiving
interface
T: optical
transmitting
interface
-
B Engineering Labels for Cables
Quidway S5300 Series Ethernet Switches
Quick Start
B-12 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2008-12-26)
