Appearance of the S5352C-EI
The chassis of the S5352C-EI is 1 U high with the dimensions of 442.0 x 420.0 x 43.6 mm (width
x depth x height).Figure 1-3 shows the rear view of the S5352C-EI.
Figure 1-3 Rear view of the S5352C-EI
1.3 Basic Configurations for the Device Management
This section describes the basic configurations for the device management such as configuring
IP addresses, remote login, naming the device, and setting device time.
1.3.1 Example for Configuring to Manage the S-switch Through Telnet
1.3.1 Example for Configuring to Manage the S-switch Through
Telnet
Networking Requirements
As shown in Figure 1-4, S-switch-A is newly added to the network. S-switch-A and S-switch-
B are connected through a trunk link. To enable the network administrator to manage S-switch-
A remotely, you need to configure the Telnet service and set the device name on S-switch-A.
When the administrator logs in to S-switch-A through Telnet, ensure that the PC of the
administrator and S-switch-A are reachable at the network layer.
Figure 1-4 Networking diagram of managing S-switch-A through Telnet
RS-232
Console cable
Console port
PC S-switch-A
serial port
Ethernet
administrator
S-switch-B
S-switch-C
GE 0/0/24
GE 0/0/24
Quidway S5300 Series Ethernet Switches
Quick Start 1 Quick Start
Issue 01 (2008-12-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1-3
