Content Meaning Example
ODF-MN-B-
C-R/T
MN: row number
and column
number of an
ODF
M: The cabinet rows from front to back are numbered
from A to Z.
N: The cabinet columns from left to right are numbered
from 01 to 99.
For example, G01 is the ODF of Row G and Column 01.
B: row number of
the terminal
device
Range from 01 to 99, for example, 01-01.
C: row number of
the terminal
device
R: Optical
receiving
interface
T: optical
transmitting
interface
-
Example of the Label
Figure B-10 shows the label on the cable.
Figure B-10 Example of the label on the optical fiber between the device and the ODF
ODF
R
TO:
G01 01 01
A01
R
01 05 01
Meaning of the label in Figure B-10
l “ODF-G01-01-01-R” indicates that the local end of the optical fiber is connected with the
optical receiving terminal on row 01, column 01 of the ODF in row G, column 01 in the
machine room.
l “A01-01-05-01-R” indicates that the opposite end of the optical fiber is connected with
Optical Receiving Interface 1 on Slot 01, chassis 01 in the cabinet on Row A, Column 01
in the machine room.
B.3 Engineering Labels for Network Cables
This describes the applicable ranges and contents of the engineering labels for network cables
and gives instances.
Quidway S5300 Series Ethernet Switches
Quick Start B Engineering Labels for Cables
Issue 01 (2008-12-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
B-13
