Huawei S1720-10GW2P User Manual

No
.
Indic
ator
Name Color Statu
s
Description
5 PoE PoE
indicator
- O The PoE mode is not selected.
Green Stead
y on
The service port indicators show the
PoE status. After 45 seconds, the
service port indicators automatically
restore to the status mode.
6 MO
DE
Mode
switching
button
- - ● When you press this button once,
the service port indicators show
the speed of each service port.
● When you press this button a
second time, the service port
indicators change to the PoE mode
and show the PoE status of each
service port.
● When you press this button a third
time, the STAT indicator turns
green and the service port
indicators restore to the default
mode.
If you do not press this button within
45 seconds, the service port indicators
restore to the default mode. In this
case, the STAT indicator is steady
green, the SPED and PoE indicators
are
o.
7 - Service
port
indicator
Meanings of service port indicators vary in dierent
modes. For details, see Table 5-26.
Table 5-26 Description of service port indicators in dierent modes (one indicator
for each port)
Display
Mode
Color Status Description
Status - O The port is not connected or has been
shut down.
Green Steady on A link has been established on the port.
Green Blinking The port is sending or receiving data.
Speed - O The port is not connected or has been
shut down.
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 84
