Huawei S1720-10GW2P User Manual

Indicators
Figure 5-31 Indicators on the S1720X-16XWR
S1720X-16XWR
1234567891011 12 13 14 15 16
RST
MODE
HUAWEI
SPED
STAT
SYS
PWR
ETH
16 7
5
2
43
RST
7
S1720X-16XWR
12 345
MODE
HUAWEI
SPED
STAT
SYS
PWR
16
5
2
43
ETH
ETH
Table 5-35 Description of indicators on the switch
No
.
Indic
ator
Name Color Statu
s
Description
1 PWR Power
indicator
- O The switch is powered o.
Green Stead
y on
The system power supply is normal.
2 SYS System
status
indicator
- O The system is not running.
Green Fast
blinki
ng
The system is starting.
Green Slow
blinki
ng
The system is running normally.
Red Stead
y on
The system does not work normally
after registration, or a fan alarm or
temperature alarm has been
generated.
3 STAT Status
indicator
- O The status mode is not selected.
Green Stead
y on
The status mode (default mode) is
selected. If the status mode is
selected, the service port indicator
shows the port link or activity state.
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 119
