Huawei S1720-10GW2P User Manual

No
.
Indic
ator
Name Color Statu
s
Description
4 SPED Speed
indicator
- O The speed mode is not selected.
Green Stead
y on
The service port indicators show the
port speeds. After 45 seconds, the
service port indicators automatically
restore to the status mode.
5 MO
DE
Mode
switching
button
- - ● When you press this button once,
the service port indicators change
to the speed mode and show the
speed of each service port.
● When you press this button again,
the service port indicators restore
to the default mode, and the STAT
indicator turns green.
If you do not press the MODE button
within 45 seconds, the service port
indicators restore to the default
mode. In this case, the STAT indicator
is steady green, the SPED indicator is
o.
6 - 10GE
service
port
indicator
(two
indicator
s for
each
port)
Meanings of service port indicators vary in dierent
modes. For details, see Table 5-36.
7 - ETH port
indicator
- O The ETH port is not connected.
Green Stead
y on
The ETH port is connected.
Green Blinki
ng
The ETH port is sending or receiving
data.
Table 5-36 Description of 10GE service port indicators in dierent modes (two
indicators for each port)
Display
Mode
Color Status Description
Status - O The port is not connected or has been
shut down.
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 120
