1 Twenty-four 10/100/1000BASE-T
ports
2 Four 1000BASE-X ports
Applicable modules and cables:
● GE optical module
● GE-CWDM optical module
● GE-DWDM optical module
● GE copper transceiver module
3 One console port 4 One ETH management port
5 One USB port 6 One RST button
NOTICE
If you hold down the Reset button for
at least 6 seconds, the switch restores
factory settings and then is reset.
If you press the Reset button, the
switch is reset.
Resetting the switch will cause service
interruption. Exercise caution when you
press the Reset button.
7 Ground screw 8 Jack reserved for AC power cable
locking strap
NOTE
The AC power cable locking strap is not
delivered with the switch.
9 AC power socket - -
Port Description
10/100/1000BASE-T port
A 10/100/1000BASE-T Ethernet electrical port sends and receives service data at
10/100/1000 Mbit/s. Table 5-39 describes the attributes of a 10/100/1000BASE-T
Ethernet electrical port.
Table 5-39 Attributes of a 10/100/1000BASE-T Ethernet electrical port
Attribute Description
Connector type RJ45
Standards
compliance
IEEE802.3, IEEE802.3u, IEEE802.3ab
Working mode 10/100/1000 Mbit/s auto-sensing
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 128
