9 AC power socket - -
Port Description
10/100/1000BASE-T port
A 10/100/1000BASE-T Ethernet electrical port sends and receives service data at
10/100/1000 Mbit/s. Table 5-66 describes the attributes of a 10/100/1000BASE-T
Ethernet electrical port.
Table 5-66 Attributes of a 10/100/1000BASE-T Ethernet electrical port
Attribute Description
Connector type RJ45
Standards
compliance
IEEE802.3, IEEE802.3u, IEEE802.3ab
Working mode 10/100/1000 Mbit/s auto-sensing
Maximum
transmission
distance
100 m
10GE SFP+ port
A 10GE SFP+ Ethernet optical port supports auto-negotiation to 1000 Mbit/s. It
sends and receives service data at 1000 Mbit/s or 10 Gbit/s. Table 5-67 describes
the attributes of a 10GE SFP+ Ethernet optical port.
Table 5-67 Attributes of a 10GE SFP+ Ethernet optical port
Attribute Description
Connector type LC/PC
Optical port
attributes
Depend on the optical module used
Standards
compliance
IEEE802.3ae
Working mode 10GE/GE auto-negotiation
Console port
The console port is connected to a console for on-site
conguration. Table 5-68
describes the attributes of the console port.
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 161
