Indicators
NO TE
Hold down the mode switch button for 6s and release it to start the web initial login mode.
Either of the following situations will occur:
● If the switch has no conguration le, the system attempts to enter the web initial
login mode. In this mode, the status of mode indicators is as follows:
● If the system enters the web initial login mode successfully, all mode indicators
turn green and stay on for a maximum of 10 minutes.
● If the system fails to enter the initial login mode, all mode indicators fast blink
for 10 seconds and then restore the default status.
● If the switch has a conguration le, the system cannot enter the web initial login
mode. In this case, all mode indicators fast blink for 10s, and then return to the
default states.
Figure 5-42 Indicators on an S1730S-H24T4S-A
CloudEngine S1730S-H24T4S-A
PWR
SYS
SPEED
MODE
12 34 56 78 910 11 1 2 13 14 15 16 17 18 19 20 21 22 23 24
25
26 27
GE
ETH
CONSOLE
28
ID
L/A
USB
RST
12
3
6875 5
CloudEngine S1730S-H24T4S-A
PWR
SYS
SPEED
MODE
12 34 56 7
1
2
3
4
5
27
GE
ETH
CONSOLE
28
ID
L/A
USB
RST
687
5
Table 5-81 Description of indicators on an S1730S-H24T4S-A
No
.
Indic
ator
Name Color Statu
s
Description
1 PWR Power
indicator
- O The switch is powered o.
Green Stead
y on
The switch is powered on.
2 SYS System
status
indicator
- O The system is not running.
Green Fast
blinki
ng
The system is starting.
Green Stead
y on
In the system startup preparation
phase, the SYS indicator is steady
green for no more than 30 seconds.
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 175
