Huawei S1720-10GW2P User Manual

No
.
Indic
ator
Name Color Statu
s
Description
Green Slow
blinki
ng
The system is running normally.
Red Stead
y on
The system does not work normally
after registration, or a fan alarm or
temperature alarm has been
generated.
3 SPEE
D
Speed
indicator
- O The speed mode is not selected.
Green Stead
y on
The speed mode is selected, and
service port indicators show the speed
of each port.
4 MO
DE
Mode
switching
button
- - ● When you press this button once,
the service port indicators change
to the speed mode and show the
speed of each service port.
● When you press this button a third
time, the service port indicators
restore to the default mode and
show the connection status of each
service port.
If you do not press the MODE button
within 45 seconds, the service port
indicators restore to the default
mode. In this case, the SPEED
indicator is
o.
5 - Service
port
indicator
Meanings of service port indicators vary in dierent
modes. For details, see Table 5-82.
6 ID ID
indicator
- O The ID indicator is disabled (default
status).
Blue Stead
y on
The ID indicator is enabled remotely
by O&M personnel for fault locating.
7 L/A ETH port
indicator
- O The ETH port is not connected.
Green Stead
y on
The ETH port is connected.
Green Blinki
ng
The ETH port is sending or receiving
data.
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 176
