The S1730S-S24T4S-A, S1730S-S24T4S-MA, and S1730S-H24T4S-A switches adopt natural
heat dissipation, and heat is dissipated from the bottom shell, leading to a high
temperature of the shell even at ambient temperature. To prevent injuries, do not touch the
bottom shell. Additionally, you must install these switches in a well-ventilated area with
restricted access (not accessible to unskilled personnel), instead of on a desk or in an
airtight cabinet. It is recommended that the switches be installed in a well-ventilated
network box or cabinet.
Some switch models support security slot. To determine whether a security lock can be
installed, check for the security slot marked with a padlock icon on the chassis. See Figure
4-3. If there is no security slot on the switch, it means that the security lock is not
supported.
The security slot is 7 mm long and 3 mm wide. The maximum radius of its four round
corners is 1 mm.
Figure 4-3 Security slot marked with padlock icon
S1700 Managed Series Ethernet Switches
Product Description
4 Application Scenarios
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 17
