Power Supply Conguration
The S1728GWR-4P has a built-in power module and does not support pluggable
power modules.
Heat Dissipation
The S1728GWR-4P has no fans and uses natural heat dissipation.
Technical
Specications
Table 5-8 lists technical specications of the S1728GWR-4P.
Table 5-8 Technical specications
Item Description
Memory (RAM) 128 MB
Flash 32 MB
Mean time
between failures
(MTBF)
24.65 years
Mean time to
repair (MTTR)
2 hours
Availability > 0.99999
Dimensions (H x
W x D)
43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.7
in.)
Weight
(including
packaging)
< 3 kg (6.62 lb)
Stack ports Not supported
RTC Not supported
RPS Not supported
PoE Not supported
Rated voltage
range
100 V AC to 240 V AC, 50/60 Hz
Maximum
voltage range
90 V AC to 264 V AC, 47 Hz to 63 Hz
Maximum power
consumption
(100%
throughput)
15 W
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 33
