3 Two 1000BASE-X Ethernet ports
Applicable modules:
● GE optical module (the
maximum transmission distance
cannot exceed 40 km)
● GE copper transceiver module
● GPON optical module
(applicable in V200R012C00 and
later versions)
NOTE
If a port uses a GPON optical module,
other 1000BASE-X optical ports cannot
be used.
4 Reset button
NOTICE
To restore the factory settings of a
switch, hold down the Reset button for
at least 6 seconds. This operation will
not reset the switch.
To reset a switch, press the Reset
button.
Resetting the switch will cause service
interruption. Exercise caution when you
press the Reset button.
5 AC power socket
NOTE
It is used with an AC power cable.
6 Jack reserved for AC power cable
locking strap
NOTE
The AC power cable locking strap is not
delivered with the switch.
Indicators
The S1720-10GW-2P does not have the PoE indicator. The meanings of other
indicators are the same as those on the S1720-10GW-PWR-2P.
Power Supply
Conguration
The S1720-10GW-2P has a built-in power module and does not support pluggable
power modules.
Heat Dissipation
The S1720-10GW-2P has no fans and uses natural heat dissipation.
Technical
Specications
Table 5-14 lists technical specications of the S1720-10GW-2P.
Table 5-14 Technical
specications
Item Description
Memory (RAM) 512 MB
Flash 512 MB in total, 240 MB available for customers
Mean time
between failures
(MTBF)
23.8 years
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 46
