Item SUN2000-12
5KTL-M0
SUN2000-11
0KTL-M0
SUN2000-10
0KTL-M0
SUN2000-100KT
L-M1
SUN2000-10
0KTL-INM0
Rated
output
voltage
a
(phase
voltage/line
voltage)
288 V/500 V,
3W + PE
220 V/380 V
and 230
V/400 V, 3W
+ (N)
b
+ PE
220 V/380 V
and 230
V/400 V, 3W
+ (N)
b
+ PE
220 V/380 V, 230
V/400 V, and 277
V/480 V, 3W +
(N)
b
+ PE
240 V/415 V
and 277
V/480 V, 3W
+ (N)
b
+ PE
Rated
output
current
144.4 A 167.2 A (380
V) and 158.8
A (400 V)
152.0 A (380
V) and 144.4
A (400 V)
152.0 A (380 V),
144.4 A (400 V),
and 120.3 A (480
V)
139.2 A (415
V) and 120.3
A (480 V)
Adapted
power grid
frequency
50 Hz 50 Hz/60 Hz 50 Hz/60 Hz 50 Hz/60 Hz 50 Hz/60 Hz
Maximum
output
current
160.4 A 185.7 A (380
V) and 176.4
A (400 V)
168.8 A (380
V) and 160.4
A (400 V)
168.8 A (380 V),
160.4 A (400 V),
and 133.7 A (480
V)
154.6 A (415
V), 133.7 A
(480 V)
Power
factor
0.8 leading and 0.8 lagging
Maximum
total
harmonic
distortion
(rated
power)
< 3%
Note a: The rated output voltage is determined by Grid code, which can be set on the SUN2000
app, SmartLogger, or NMS.
Note b: You can determine whether to connect the neutral wire to the SUN2000-110KTL-M0,
SUN2000-100KTL-M0, SUN2000-100KTL-M1, or SUN2000-100KTL-INM0 based on the application
scenario. If no neutral wire is used, set Output mode to Three-phase three-wire. If the neutral
wire is used, set the Output mode to Three-phase four-wire.
Protection
Item
SUN2000-12
5KTL-M0
SUN2000-11
0KTL-M0
SUN2000-10
0KTL-M0
SUN2000-100KT
L-M1
SUN2000-10
0KTL-INM0
AFCI - Optional -
PID
recovery
- Optional -
Input DC
switch
Supported
SUN2000-(100KTL, 110KTL, 125KTL) Series
User Manual 10 Technical Specications
Issue 07 (2020-09-15) Copyright © Huawei Technologies Co., Ltd. 127
