Symbol Name Meaning
Grounding Indicates the position for connecting
the protective earthing (PE) cable.
Operation warning Do not remove the DC input
connector when the inverter is
running.
Fan operation warning High voltage exists after the inverter
is powered on. Do not touch the
fans when the inverter is working.
Fan replacement warning Before replacing a fan, disconnect its
power connectors.
Inverter ESN label Indicates the inverter serial number.
Weight label The inverter needs to be carried by
four persons or using a pallet truck.
2.4 Product Appearance
SUN2000-(100KTL, 110KTL, 125KTL) Series
User Manual 2 Overview
Issue 07 (2020-09-15) Copyright © Huawei Technologies Co., Ltd. 12
